Delphi，VC++，VB，C#等實現二維條碼繪制

/*Title:Delphi，VC++，VB，C#等實現二維條碼繪制

*Author:Insun

*Blog:http://yxmhero1989.blog.163.com

*From:www.4safer.com

*/

先認識幾個基本概念：

PDF417  ----條形碼
2D BarCode ---二維碼- --  QRCode  ---Quick Response Code 二維空間碼
DataMatrix  -- 數據矩陣

 其他參見我的：關於二維碼(About 2D Barcode) http://yxmhero1989.blog.163.com/blog/static/11215795620110172842999/

Data　Matrix 二維條碼的發展 http://www.systron.com.cn/datamatrix.htm

ECC200原始出處是 DataMatrix，官方網址在http://www.neodynamic.com/barcodes/DataMatrix_Barcode.aspx

先說Delphi實現二維條碼繪制，需要用到ECC200.pas和ReedSolomon.pas

uses ECC200,ReedSolomon;

否則肯定找不到ReedSolomon.dcu 和ECC200.dcu啦。
[Fatal Error] ECC200.pas(569): File not found: ReedSolomon.dcu

由於pudn上有個源碼

《delphi實現的二 維 碼 生成 控制代 碼-delphi realize two-dimensional code generated control code》

ECC200.pas：http://read.pudn.com/downloads111/sourcecode/delphi_control/460570/Delphi/ECC200.pas__.htm

ReedSolomon.pas：http://read.pudn.com/downloads111/sourcecode/delphi_control/460570/Delphi/ReedSolomon.pas__.htm

Reed–Solomon error correction 關於Reed–Solomon糾錯碼 可以看：http://en.wikipedia.org/wiki/Reed%E2%80%93Solomon_error_correction

關於reed-solomon codes 老外有篇算法論文：
http://ptgmedia.pearsoncmg.com/images/art_sklar7_reed-solomon/elementLinks/art_sklar7_reed-solomon.pdf

      procedure Generate2DCode(AStr: string; ASize: Integer; ABmp: TBitmap);
var
s : TByteArray;
m : TByteArray;
i, j: Integer;
w, h : integer;
cc: Integer;
begin
if not Assigned(ABmp) then
Exit;
SetLength(s, Length(AStr));
for i := 1 to Length(AStr) do
begin
s[i-1] := Ord(AStr[i]);
end;
 CalcECC200(s, ecc200_Autosize, ecc200_Square, m, w, h); // ECC200.pas
ABmp.Width := w * ASize;
ABmp.Height := h * ASize;
for i := 0 to h - 1 do
begin
for j := 0 to w - 1 do
begin
cc := m[i * w + j];
if cc = 1 then
begin
ABmp.Canvas.Brush.Color := clBlack;
ABmp.Canvas.Rectangle(Rect(
j*ASize,
i*ASize,
j*ASize+ASize,
i*ASize+ASize));
end;
end;
end;
end;

調用很簡單：

    procedure TForm1.FormCreate(Sender: TObject);
var
bmp: TBitmap;
begin
bmp:=TBitmap.Create;
  // 第二個參數表示每個小格的邊長
Generate2DCode(Insun祝您新年快樂  Blog：http://yxmhero1989.blog.163.com , 2, bmp);
  // TODO: your code here
     //bmp.SaveToFile(1.bmp);
     Image1.Picture.Assign(bmp);
bmp.Free;
end;

如圖所示：

 References：

1。使用ECC200繪制二維碼

http://hi.baidu.com/rarnu/blog/item/373ead772ee40010b151b9d1.html

2.。VB MakeTwoBarCode.rar (125.79 kB) 源代碼下載
http://www.hackchina.com/dlpre.php?id=194965

3。C# 實現QRCode
http://www.pudn.com/downloads136/sourcecode/windows/csharp/detail581330.html

http://www.7880.com/download/ewbm-22338.html

4。QRcodeDecoder.rar  VC++
http://www.hackchina.com/cont/76458
5.。利用QRmaker制作二維碼
http://windyli.blog.51cto.com/1300305/284574

6
http://www.barcommune.com/Pdf417.html
7。Java解析與生成二維碼的源碼下載
http://download.csdn.net/source/2580954
