c#-C# 請教這個設置多顯示器復制擴展的類怎麼調用?麻煩各位了!

編輯:編程綜合問答
C# 請教這個設置多顯示器復制擴展的類怎麼調用?麻煩各位了!
 #region Copyright (C) 2005-2011 Team MediaPortal

// Copyright (C) 2005-2011 Team MediaPortal
// http://www.team-mediaportal.com
//
// MediaPortal is free software: you can redistribute it and/or modify
// it under the terms of the GNU General Public License as published by
// the Free Software Foundation, either version 2 of the License, or
// (at your option) any later version.
//
// MediaPortal is distributed in the hope that it will be useful,
// but WITHOUT ANY WARRANTY; without even the implied warranty of
// MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
// GNU General Public License for more details.
//
// You should have received a copy of the GNU General Public License
// along with MediaPortal. If not, see <http://www.gnu.org/licenses/>.

#endregion

#region using

using System;
using System.Collections.Generic;
using System.Text;
using System.Runtime.InteropServices;

#endregion

namespace ImageViewer
{
    public class W7RefreshRateHelper
    {
        #region consts

        private const uint SIZE_OF_DISPLAYCONFIG_PATH_INFO = 72;
        private const uint SIZE_OF_DISPLAYCONFIG_MODE_INFO = 64;

        private const uint QDC_ALL_PATHS = 1;
        private const uint DISPLAYCONFIG_MODE_INFO_TYPE_TARGET = 2;
        private const uint DISPLAYCONFIG_SCANLINE_ORDERING_PROGRESSIVE = 1;
        public const uint SDC_TOPOLOGY_INTERNAL = 0x00000001;
        public const uint SDC_TOPOLOGY_CLONE = 0x00000002;
        public const uint SDC_TOPOLOGY_EXTEND = 0x00000004;
        public const uint SDC_TOPOLOGY_EXTERNAL = 0x00000008;
        public const uint SDC_TOPOLOGY_SUPPLIED = 0x00000010;
        public const uint SDC_USE_DATABASE_CURRENT = (SDC_TOPOLOGY_INTERNAL | SDC_TOPOLOGY_CLONE | SDC_TOPOLOGY_EXTEND | SDC_TOPOLOGY_EXTERNAL);

        private const uint SDC_USE_SUPPLIED_DISPLAY_CONFIG = 0x00000020;
        private const uint SDC_VALIDATE = 0x00000040;
        private const uint SDC_APPLY = 0x00000080;
        private const uint SDC_ALLOW_CHANGES = 0x00000400;

        private const uint SDC_NO_OPTIMIZATION = 0x00000100;
        private const uint SDC_SAVE_TO_DATABASE = 0x00000200;
        private const uint SDC_PATH_PERSIST_IF_REQUIRED = 0x00000800;
        private const uint SDC_FORCE_MODE_ENUMERATION = 0x00001000;
        private const uint SDC_ALLOW_PATH_ORDER_CHANGES = 0x00002000;

        #endregion

        #region DLL imports

        [DllImport("user32.dll", CharSet = CharSet.Unicode)]
        private static extern long GetDisplayConfigBufferSizes([In] uint flags, [Out] out uint numPathArrayElements,
                                                               [Out] out uint numModeArrayElements);

        [DllImport("user32.dll", CharSet = CharSet.Unicode)]
        private static extern long QueryDisplayConfig([In] uint flags, ref uint numPathArrayElements, IntPtr pathArray,
                                                      ref uint numModeArrayElements, IntPtr modeArray,
                                                      IntPtr currentTopologyId);

        [DllImport("user32.dll", CharSet = CharSet.Unicode)]
        private static extern long SetDisplayConfig(uint numPathArrayElements, IntPtr pathArray, uint numModeArrayElements,
                                                    IntPtr modeArray, uint flags);

        #endregion

        #region private members

        private static int GetModeInfoOffsetForDisplayId(uint displayIndex, IntPtr pModeArray, uint uNumModeArrayElements)
        {
            int offset;
            int modeInfoType;

            // there are always two mode infos per display (target and source)
            offset = (int)(displayIndex * SIZE_OF_DISPLAYCONFIG_MODE_INFO * 2);

            // out of bounds sanity check
            if (offset + SIZE_OF_DISPLAYCONFIG_MODE_INFO >= uNumModeArrayElements * SIZE_OF_DISPLAYCONFIG_MODE_INFO)
            {
                return -1;
            }

            // check which one of the two mode infos for the display is the target
            modeInfoType = Marshal.ReadInt32(pModeArray, offset);
            if (modeInfoType == DISPLAYCONFIG_MODE_INFO_TYPE_TARGET)
            {
                return offset;
            }
            else
            {
                offset += (int)SIZE_OF_DISPLAYCONFIG_MODE_INFO;
            }

            modeInfoType = Marshal.ReadInt32(pModeArray, offset);
            if (modeInfoType == DISPLAYCONFIG_MODE_INFO_TYPE_TARGET)
            {
                return offset;
            }
            // no target mode info found, this should never happen
            else
            {
                return -1;
            }
        }

        #endregion

        #region public members

        public static double GetRefreshRate(uint displayIndex)
        {
            uint uNumPathArrayElements = 0;
            uint uNumModeArrayElements = 0;
            IntPtr pPathArray = IntPtr.Zero;
            IntPtr pModeArray = IntPtr.Zero;
            IntPtr pCurrentTopologyId = IntPtr.Zero;
            long result;
            UInt32 numerator;
            UInt32 denominator;
            double refreshRate;

            // get size of buffers for QueryDisplayConfig
            result = GetDisplayConfigBufferSizes(QDC_ALL_PATHS, out uNumPathArrayElements, out uNumModeArrayElements);
            if (result != 0)
            {
                //   Log.Error("W7RefreshRateHelper.GetRefreshRate: GetDisplayConfigBufferSizes(...) returned {0}", result);
                return 0;
            }

            // allocate memory or QueryDisplayConfig buffers
            pPathArray = Marshal.AllocHGlobal((Int32)(uNumPathArrayElements * SIZE_OF_DISPLAYCONFIG_PATH_INFO));
            pModeArray = Marshal.AllocHGlobal((Int32)(uNumModeArrayElements * SIZE_OF_DISPLAYCONFIG_MODE_INFO));

            // get display configuration
            result = QueryDisplayConfig(QDC_ALL_PATHS,
                                        ref uNumPathArrayElements, pPathArray,
                                        ref uNumModeArrayElements, pModeArray,
                                        pCurrentTopologyId);
            // if failed log error message and free memory
            if (result != 0)
            {
                //   Log.Error("W7RefreshRateHelper.GetRefreshRate: QueryDisplayConfig(...) returned {0}", result);
                Marshal.FreeHGlobal(pPathArray);
                Marshal.FreeHGlobal(pModeArray);
                return 0;
            }

            // get offset for a display's target mode info
            int offset = GetModeInfoOffsetForDisplayId(displayIndex, pModeArray, uNumModeArrayElements);
            // if failed log error message and free memory
            if (offset == -1)
            {
                //Log.Error("W7RefreshRateHelper.GetRefreshRate: Couldn't find a target mode info for display {0}", displayIndex);
                Marshal.FreeHGlobal(pPathArray);
                Marshal.FreeHGlobal(pModeArray);
                return 0;
            }

            // get refresh rate
            numerator = (UInt32)Marshal.ReadInt32(pModeArray, offset + 32);
            denominator = (UInt32)Marshal.ReadInt32(pModeArray, offset + 36);
            refreshRate = (double)numerator / (double)denominator;
            //Log.Debug("W7RefreshRateHelper.GetRefreshRate: QueryDisplayConfig returned {0}/{1}", numerator, denominator);

            // free memory and return refresh rate
            Marshal.FreeHGlobal(pPathArray);
            Marshal.FreeHGlobal(pModeArray);
            return refreshRate;
        }


        public static bool SetRefreshRate(uint displayIndex, double refreshRate)
        {
            uint uNumPathArrayElements = 0;
            uint uNumModeArrayElements = 0;
            IntPtr pPathArray = IntPtr.Zero;
            IntPtr pModeArray = IntPtr.Zero;
            IntPtr pCurrentTopologyId = IntPtr.Zero;
            long result;
            UInt32 numerator;
            UInt32 denominator;
            UInt32 scanLineOrdering;
            UInt32 flags;

            // get size of buffers for QueryDisplayConfig
            result = GetDisplayConfigBufferSizes(QDC_ALL_PATHS, out uNumPathArrayElements, out uNumModeArrayElements);
            if (result != 0)
            {
                // Log.Error("W7RefreshRateHelper.GetRefreshRate: GetDisplayConfigBufferSizes(...) returned {0}", result);
                return false;
            }

            // allocate memory or QueryDisplayConfig buffers
            pPathArray = Marshal.AllocHGlobal((Int32)(uNumPathArrayElements * SIZE_OF_DISPLAYCONFIG_PATH_INFO));
            pModeArray = Marshal.AllocHGlobal((Int32)(uNumModeArrayElements * SIZE_OF_DISPLAYCONFIG_MODE_INFO));

            // get display configuration
            result = QueryDisplayConfig(QDC_ALL_PATHS,
                                        ref uNumPathArrayElements, pPathArray,
                                        ref uNumModeArrayElements, pModeArray,
                                        pCurrentTopologyId);
            // if failed log error message and free memory
            if (result != 0)
            {
                //   Log.Error("W7RefreshRateHelper.GetRefreshRate: QueryDisplayConfig(...) returned {0}", result);
                Marshal.FreeHGlobal(pPathArray);
                Marshal.FreeHGlobal(pModeArray);
                return false;
            }

            // get offset for a display's target mode info
            int offset = GetModeInfoOffsetForDisplayId(displayIndex, pModeArray, uNumModeArrayElements);
            // if failed log error message and free memory
            if (offset == -1)
            {
                //Log.Error("W7RefreshRateHelper.GetRefreshRate: Couldn't find a target mode info for display {0}", displayIndex);
                Marshal.FreeHGlobal(pPathArray);
                Marshal.FreeHGlobal(pModeArray);
                return false;
            }

            // TODO: refactor to private method
            // set proper numerator and denominator for refresh rate
            UInt32 newRefreshRate = (uint)(refreshRate * 1000);
            switch (newRefreshRate)
            {
                case 23976:
                    numerator = 24000;
                    denominator = 1001;
                    scanLineOrdering = DISPLAYCONFIG_SCANLINE_ORDERING_PROGRESSIVE;
                    break;
                case 24000:
                    numerator = 24000;
                    denominator = 1000;
                    scanLineOrdering = DISPLAYCONFIG_SCANLINE_ORDERING_PROGRESSIVE;
                    break;
                case 25000:
                    numerator = 25000;
                    denominator = 1000;
                    scanLineOrdering = DISPLAYCONFIG_SCANLINE_ORDERING_PROGRESSIVE;
                    break;
                case 30000:
                    numerator = 30000;
                    denominator = 1000;
                    scanLineOrdering = DISPLAYCONFIG_SCANLINE_ORDERING_PROGRESSIVE;
                    break;
                case 50000:
                    numerator = 50000;
                    denominator = 1000;
                    scanLineOrdering = DISPLAYCONFIG_SCANLINE_ORDERING_PROGRESSIVE;
                    break;
                case 59940:
                    numerator = 60000;
                    denominator = 1001;
                    scanLineOrdering = DISPLAYCONFIG_SCANLINE_ORDERING_PROGRESSIVE;
                    break;
                case 60000:
                    numerator = 60000;
                    denominator = 1000;
                    scanLineOrdering = DISPLAYCONFIG_SCANLINE_ORDERING_PROGRESSIVE;
                    break;
                default:
                    numerator = (uint)(newRefreshRate / 1000);
                    denominator = 1;
                    scanLineOrdering = DISPLAYCONFIG_SCANLINE_ORDERING_PROGRESSIVE;
                    break;
            }

            // set refresh rate parameters in display config
            Marshal.WriteInt32(pModeArray, offset + 32, (int)numerator);
            Marshal.WriteInt32(pModeArray, offset + 36, (int)denominator);
            Marshal.WriteInt32(pModeArray, offset + 56, (int)scanLineOrdering);

            // validate new refresh rate
            flags = SDC_VALIDATE | SDC_USE_SUPPLIED_DISPLAY_CONFIG;

            result = SetDisplayConfig(uNumPathArrayElements, pPathArray, uNumModeArrayElements, pModeArray, flags);

            // adding SDC_ALLOW_CHANGES to flags if validation failed
            if (result != 0)
            {
                //Log.Debug("W7RefreshRateHelper.SetDisplayConfig(...): SDC_VALIDATE of {0}/{1} failed", numerator, denominator);
                flags = SDC_APPLY | SDC_USE_SUPPLIED_DISPLAY_CONFIG | SDC_ALLOW_CHANGES;


            }
            else
            {
                //Log.Debug("W7RefreshRateHelper.SetDisplayConfig(...): SDC_VALIDATE of {0}/{1} succesful", numerator, denominator);
                flags = SDC_APPLY | SDC_USE_SUPPLIED_DISPLAY_CONFIG;

            }

            // configuring display

            result = SetDisplayConfig(uNumPathArrayElements, pPathArray, uNumModeArrayElements, pModeArray, flags);

            // if failed log error message and free memory
            if (result != 0)
            {
                //Log.Error("W7RefreshRateHelper.SetDisplayConfig(...): SDC_APPLY returned {0}", result);
                Marshal.FreeHGlobal(pPathArray);
                Marshal.FreeHGlobal(pModeArray);
                return false;
            }

            // refresh rate change successful
            Marshal.FreeHGlobal(pPathArray);
            Marshal.FreeHGlobal(pModeArray);
            return true;
        }
        public static bool SetScreen(uint displayModel)
        {
            return SetDisplayConfig(0, IntPtr.Zero, 0, IntPtr.Zero, SDC_APPLY | displayModel) == 0;
        }
        #endregion
    }
}

最佳回答:


因為這個類裡面的方法都是靜態的,所以你可以直接使用類似ImageViewer.W7RefreshRateHelper.SetScreen(1)的方式調用,不需要實例化。
