詳解Oracle dg 三種模式切換，oracledg

編輯：Oracle教程

詳解Oracle dg 三種模式切換，oracledg

oracle dg 三大模式切換

===================================
1 最大性能模式MAXIMUM PERFORMANCE ------默認模式
===================================

一最大性能模式特點

192.168.1.181
SQL> select database_role,protection_mode,protection_level from v$database;
DATABASE_ROLE  PROTECTION_MODE   PROTECTION_LEVEL
---------------- -------------------- --------------------
PRIMARY     MAXIMUM PERFORMANCE MAXIMUM PERFORMANCE
SQL> col dest_name for a25
SQL> select dest_name,status from v$archive_dest_status;
DEST_NAME         STATUS
------------------------- ---------
LOG_ARCHIVE_DEST_1    VALID
LOG_ARCHIVE_DEST_2    VALID
SQL> show parameter log_archive
NAME                 TYPE    VALUE
------------------------------------ ----------- ------------------------------
log_archive_config          string   dg_config=(orcl,db01)
log_archive_dest_1          string   location=/home/oracle/arch_orc
                         l valid_for=(all_logfiles,all_
                         roles) db_unique_name=orcl
log_archive_dest_2          string   service=db_db01 LGWR ASYNC val
                         id_for=(online_logfiles,primar
                         y_roles) db_unique_name=db01
SQL> archive log list
Database log mode       Archive Mode
Automatic archival       Enabled
Archive destination      /home/oracle/arch_orcl
Oldest online log sequence   31
Next log sequence to archive  33
Current log sequence      33
192.168.1.183
SQL> select database_role,protection_mode,protection_level from v$database;
DATABASE_ROLE  PROTECTION_MODE   PROTECTION_LEVEL
---------------- -------------------- --------------------
PHYSICAL STANDBY MAXIMUM PERFORMANCE MAXIMUM PERFORMANCE
SQL> col dest_name for a25
SQL> select dest_name,status from v$archive_dest_status;
DEST_NAME         STATUS
------------------------- ---------
LOG_ARCHIVE_DEST_1    VALID
LOG_ARCHIVE_DEST_2    VALID
SQL> show parameter log_archive
NAME                 TYPE    VALUE
------------------------------------ ----------- ------------------------------
log_archive_config          string   dg_config=(db01,orcl)
log_archive_dest_1          string   location=/home/oracle/arch_db0
                         1 valid_for=(all_logfiles,all_
                         roles) db_unique_name=db01
log_archive_dest_2          string   service=db_orcl LGWR ASYNC val
                         id_for=(online_logfiles,primar
                         y_roles) db_unique_name=orcl
SQL> archive log list
Database log mode       Archive Mode
Automatic archival       Enabled
Archive destination      /home/oracle/arch_orcl
Oldest online log sequence   31
Next log sequence to archive  33
Current log sequence      33
192.168.1.181
SQL> alter system switch logfile;
SQL> archive log list
Database log mode       Archive Mode
Automatic archival       Enabled
Archive destination      /home/oracle/arch_orcl
Oldest online log sequence   32
Next log sequence to archive  34
Current log sequence      34
192.168.1.183
SQL> archive log list
Database log mode       Archive Mode
Automatic archival       Enabled
Archive destination      /home/oracle/arch_db01
Oldest online log sequence   32
Next log sequence to archive  0
Current log sequence      34

===================================
2 最大性能模式--切換到-->最大高可用 (默認是最大性能模式---MAXIMUM PERFORMANCE)
===================================

192.168.1.181
SQL> select DATABASE_ROLE,PROTECTION_MODE,PROTECTION_LEVEL from v$database;
DATABASE_ROLE  PROTECTION_MODE   PROTECTION_LEVEL
---------------- -------------------- --------------------
PRIMARY     MAXIMUM PERFORMANCE MAXIMUM PERFORMANCE
SQL> show parameter log_archive_dest_2
NAME                 TYPE    VALUE
------------------------------------ ----------- ------------------------------
log_archive_dest_2          string   service=db_db01 LGWR ASYNC val
                         id_for=(online_logfiles,primar
                         y_roles) db_unique_name=db01
192.168.1.181
SQL> shutdown immediate
192.168.1.183
SQL> alter database recover managed standby database cancel;
SQL> shutdown immediate
192.168.1.181
SQL> startup mount;
SQL> alter database set standby database to maximize availability;
SQL> alter system set log_archive_dest_2='service=db_db01 LGWR SYNC valid_for=(online_logfiles,primary_roles) db_unique_name=db01' scope=spfile;
192.168.1.183
SQL> startup nomount
SQL> alter database mount standby database;
SQL> alter system set log_archive_dest_2='service=db_orcl LGWR SYNC valid_for=(online_logfiles,primary_roles) db_unique_name=orcl' scope=spfile;
SQL> shutdown immediate
SQL> startup nomount
SQL> alter database mount standby database;
192.168.1.181
SQL> startup
SQL> col dest_name for a25
SQL> select dest_name,status from v$archive_dest_status;
DEST_NAME         STATUS
------------------------- ---------
LOG_ARCHIVE_DEST_1    VALID
LOG_ARCHIVE_DEST_2    VALID
SQL> show parameter log_archive_dest_2
NAME                 TYPE    VALUE
------------------------------------ ----------- ------------------------------
log_archive_dest_2          string   service=db_db01 LGWR SYNC vali
                         d_for=(online_logfiles,primary
                         _roles) db_unique_name=db01
SQL> select database_role,protection_level,protection_mode from v$database;
DATABASE_ROLE  PROTECTION_LEVEL   PROTECTION_MODE
---------------- -------------------- --------------------
PRIMARY     MAXIMUM AVAILABILITY MAXIMUM AVAILABILITY
SQL> archive log list
Database log mode       Archive Mode
Automatic archival       Enabled
Archive destination      /home/oracle/arch_orcl
Oldest online log sequence   34
Next log sequence to archive  36
Current log sequence      36
192.168.1.183
SQL> col dest_name for a25
SQL> select dest_name,status from v$archive_dest_status;
DEST_NAME         STATUS
------------------------- ---------
LOG_ARCHIVE_DEST_1    VALID
LOG_ARCHIVE_DEST_2    VALID
SQL> show parameter log_archive_dest_2
NAME                 TYPE    VALUE
------------------------------------ ----------- ------------------------------
log_archive_dest_2          string   service=db_orcl LGWR SYNC vali
                         d_for=(online_logfiles,primary
                         _roles) db_unique_name=orcl
SQL> select database_role,protection_level,protection_mode from v$database;
DATABASE_ROLE  PROTECTION_LEVEL   PROTECTION_MODE
---------------- -------------------- --------------------
PHYSICAL STANDBY MAXIMUM AVAILABILITY MAXIMUM AVAILABILITY
SQL> archive log list
Database log mode       Archive Mode
Automatic archival       Enabled
Archive destination      /home/oracle/arch_db01
Oldest online log sequence   35
Next log sequence to archive  0
Current log sequence      36
192.168.1.181
SQL> alter system switch logfile;
SQL> archive log list
Database log mode       Archive Mode
Automatic archival       Enabled
Archive destination      /home/oracle/arch_orcl
Oldest online log sequence   35
Next log sequence to archive  37
Current log sequence      37
192.168.1.183
SQL> archive log list
Database log mode       Archive Mode
Automatic archival       Enabled
Archive destination      /home/oracle/arch_db01
Oldest online log sequence   36
Next log sequence to archive  0
Current log sequence      37

===================================
3 最大高可用--切換到-->最保護能模式
===================================

DG最大保護模式Maximum protection

192.168.1.181
SQL> shutdown immediate
192.168.1.183
SQL> shutdown immediate
192.168.1.181
SQL> alter database set standby database to maximize protection;
SQL> shutdown immediate
192.168.1.183
SQL> startup nomount
SQL> alter database mount standby database;
192.168.1.181
SQL> startup
SQL> col dest_name for a25
SQL> select dest_name,status from v$archive_dest_status;
DEST_NAME         STATUS
------------------------- ---------
LOG_ARCHIVE_DEST_1    VALID
LOG_ARCHIVE_DEST_2    VALID
SQL> show parameter log_archive_dest_2
NAME                 TYPE    VALUE
------------------------------------ ----------- ------------------------------
log_archive_dest_2          string   service=db_db01 LGWR SYNC vali
                         d_for=(online_logfiles,primary
                         _roles) db_unique_name=db01
SQL> select database_role,protection_level,protection_mode from v$database;
DATABASE_ROLE  PROTECTION_LEVEL   PROTECTION_MODE
---------------- -------------------- --------------------
PRIMARY     MAXIMUM PROTECTION  MAXIMUM PROTECTION
SQL> archive log list
Database log mode       Archive Mode
Automatic archival       Enabled
Archive destination      /home/oracle/arch_orcl
Oldest online log sequence   37
Next log sequence to archive  39
Current log sequence      39
192.168.1.183
SQL> col dest_name for a25
SQL> select dest_name,status from v$archive_dest_status;
DEST_NAME         STATUS
------------------------- ---------
LOG_ARCHIVE_DEST_1    VALID
LOG_ARCHIVE_DEST_2    VALID
SQL> show parameter log_archive_dest_2
NAME                 TYPE    VALUE
------------------------------------ ----------- ------------------------------
log_archive_dest_2          string   service=db_db01 LGWR SYNC vali
                         d_for=(online_logfiles,primary
                         _roles) db_unique_name=db01
SQL> select database_role,protection_level,protection_mode from v$database;
DATABASE_ROLE  PROTECTION_LEVEL   PROTECTION_MODE
---------------- -------------------- --------------------
PRIMARY     MAXIMUM PROTECTION  MAXIMUM PROTECTION
SQL> archive log list
Database log mode       Archive Mode
Automatic archival       Enabled
Archive destination      /home/oracle/arch_db01
Oldest online log sequence   37
Next log sequence to archive  0
Current log sequence      39
192.168.1.181
SQL> alter system switch logfile;
SQL> archive log list
Database log mode       Archive Mode
Automatic archival       Enabled
Archive destination      /home/oracle/arch_orcl
Oldest online log sequence   38
Next log sequence to archive  40
Current log sequence      40
192.168.1.183
SQL> archive log list
Database log mode       Archive Mode
Automatic archival       Enabled
Archive destination      /home/oracle/arch_db01
Oldest online log sequence   37
Next log sequence to archive  0
Current log sequence      40

附：Oracle DG管理模式和只讀模式相互切換

將standby數據庫開啟至只讀模式(用於primary非常忙時，可以在standby跑一些報表)

$sqlplus “/as sysdba”
SQL>startup mount
SQL>alter database open read only;
[@more@]

將只讀模式standby數據庫切換至管理模式

$sqlplus “/as sysdba”
SQL>alter database recover managed standby database disconnect from session;

將管理模式的standby數據庫切換至只讀模式

$sqlplus “/as sysdba”
SQL>alter database recover managed standby database cancel;
SQL>alter database open read only;

以上內容給大家介紹了Oracle dg 三種模式切換的相關知識，希望大家喜歡。
