深入淺析mybatis oracle BLOB類型字段保存與讀取，mybatisblob

深入淺析mybatis oracle BLOB類型字段保存與讀取，mybatisblob

一、BLOB字段

　　BLOB是指二進制大對象也就是英文Binary Large Object的所寫，而CLOB是指大字符對象也就是英文Character Large Object的所寫。其中BLOB是用來存儲大量二進制數據的；CLOB用來存儲大量文本數據。BLOB通常用來保存圖片、文件等二進制類型的數據。

二、使用mybatis操作blob

　　1、表結構如下：

create table BLOB_FIELD
(
  ID          VARCHAR2(64 BYTE)  not null,
  TAB_NAME       VARCHAR2(64 BYTE)  not null,
  TAB_PKID_VALUE    VARCHAR2(64 BYTE)  not null,
  CLOB_COL_NAME    VARCHAR2(64 BYTE)  not null,
  CLOB_COL_VALUE    CLOB,
  constraint PK_BLOB_FIELD primary key (ID)
);

　　2、實體代碼如下：

 package com.test.entity;
 import java.sql.Clob;
 /**
  * 大字段
  */
 public class BlobField {
   private String tabName;// 表名
   private String tabPkidValue;// 主鍵值
   private String blobColName;// 列名
   private byte[] blobColValue;// 列值 clob類型
   public String getTabName() {
     return tabName;
   }
   public void setTabName(String tabName) {
     this.tabName = tabName;
   }
   public String getTabPkidValue() {
     return tabPkidValue;
   }
   public void setTabPkidValue(String tabPkidValue) {
     this.tabPkidValue = tabPkidValue;
   }
   public String getBlobColName() {
     return blobColName;
   }
   public void setBlobColName(String blobColName) {
     this.blobColName = blobColName;
   }
   public byte[] getBlobColValue() {
     return blobColValue;
   }
   public void setBlobColValue(byte[] blobColValue) {
     this.blobColValue = blobColValue;
   }
 }

　　3、mybatis sql代碼如下：

 <?xml version="." encoding="UTF-" ?>
 <!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper .//EN" "http://mybatis.org/dtd/mybatis--mapper.dtd">
 <mapper namespace="com.test.dao.BlobFieldDao">
   <sql id="blobFieldColumns">
     a.ID AS id,
     a.TAB_NAME AS tabName,
     a.TAB_PKID_VALUE AS tabPkidValue,
     a.BLOB_COL_NAME AS blobColName,
     a.BLOB_COL_VALUE AS blobColValue
   </sql>
   <sql id="blobFieldJoins">
   </sql>
   <select id="get" resultType="blobField">
     SELECT
     <include refid="blobFieldColumns" />
     FROM BLOB_FIELD a
     <include refid="blobFieldJoins" />
     WHERE a.ID = #{id}
   </select>
   <select id="findList" resultType="blobField">
     SELECT
     <include refid="blobFieldColumns" />
     FROM BLOB_FIELD a
     <include refid="blobFieldJoins" />
   </select>
   <insert id="insert">
     INSERT INTO BLOB_FIELD(
     ID ,
     TAB_NAME ,
     TAB_PKID_VALUE ,
     BLOB_COL_NAME ,
     BLOB_COL_VALUE
     ) VALUES (
     #{id},
     #{tabName},
     #{tabPkidValue},
     #{blobColName},
     #{blobColValue,jdbcType=BLOB}
     )
   </insert>
   <update id="update">
     UPDATE BLOB_FIELD SET
     TAB_NAME = #{tabName},
     TAB_PKID_VALUE = #{tabPkidValue},
     BLOB_COL_NAME = #{blobColName},
     BLOB_COL_VALUE = #{blobColValue}
     WHERE ID = #{id}
   </update>
   <delete id="delete">
     DELETE FROM BLOB_FIELD
     WHERE ID = #{id}
   </delete>
 </mapper>

　　3、controller代碼如下：

　　a、保存BLOB字段代碼

/**
    * 附件上傳
    *
    * @param testId
    *      主表Id
    * @param request
    * @return
    * @throws UnsupportedEncodingException
    */
   @RequiresPermissions("exc:exceptioninfo:feedback")
   @RequestMapping(value = "attachment", method = RequestMethod.POST)
   @ResponseBody
   public Map<String, Object> uploadAttachment(@RequestParam(value = "testId", required = true) String testId,

 HttpServletRequest request)
       throws UnsupportedEncodingException {
     Map<String, Object> result = new HashMap<String, Object>();

     MultipartHttpServletRequest multipartRequest = (MultipartHttpServletRequest) request;
     // 獲得文件
     MultipartFile multipartFile = multipartRequest.getFile("Filedata");// 與前端設置的fileDataName屬性值一致
     String filename = multipartFile.getOriginalFilename();// 文件名稱
     InputStream is = null;
     try {
       //讀取文件流
       is = multipartFile.getInputStream();
       byte[] bytes = FileCopyUtils.copyToByteArray(is);
       BlobField blobField = new BlobField();
       blobField.setTabName("testL");
       blobField.setTabPkidValue(testId);
       blobField.setBlobColName("attachment");
       blobField.setBlobColValue(bytes);
       //保存blob字段
       this.testService.save(blobField, testId, filename);
       result.put("flag", true);
       result.put("attachmentId", blobField.getId());
       result.put("attachmentName", filename);
     } catch (IOException e) {
       e.printStackTrace();
       result.put("flag", false);
     } finally {
       IOUtils.closeQuietly(is);
     }
     return result;
   }

　　b、讀取BLOB字段

 /**
    * 下載附件
    *
    * @param attachmentId
    * @return
    */
   @RequiresPermissions("exc:exceptioninfo:view")
   @RequestMapping(value = "download", method = RequestMethod.GET)
   public void download(@RequestParam(value = "attachmentId", required = true) String attachmentId,
       @RequestParam(value = "attachmentName", required = true) String attachmentName, HttpServletRequest
 request, HttpServletResponse response) {
     ServletOutputStream out = null;
     try {
       response.reset();
       String userAgent = request.getHeader("User-Agent");
       byte[] bytes = userAgent.contains("MSIE") ? attachmentName.getBytes() : attachmentName.getBytes("UTF-
 "); // fileName.getBytes("UTF-")處理safari的亂碼問題
       String fileName = new String(bytes, "ISO--");
       // 設置輸出的格式
       response.setContentType("multipart/form-data");
       response.setHeader("Content-Disposition", "attachment;fileName=" + URLEncoder.encode(attachmentName,
 "UTF-"));
       BlobField blobField = this.blobFieldService.get(attachmentId);
       //獲取blob字段
       byte[] contents = blobField.getBlobColValue();
       out = response.getOutputStream();
       //寫到輸出流
       out.write(contents);
       out.flush();
     } catch (IOException e) {
       e.printStackTrace();
     }
   }

　　本例子將文件上傳並保存到BLOB類型字段字段，下載的時候讀取BLOB字段，並寫入成輸出流。

以上就是本文的全部敘述，希望對大家有所幫助。
