Implementing a fully connected neural network from scratch in Python

Keep creating , Accelerate growth ！ This is my participation 「 Nuggets day new plan · 6 Yuegengwen challenge 」 Of the 31 God , Click to see the event details

In this article , Ready to use Python A fully connected neural network is implemented from scratch . You may ask , Why do you need to implement it yourself , There are many libraries and frameworks that can do this for us , such as Tensorflow、Pytorch etc. . I just want to say that I can only realize it myself , It's your own .

I think how much I have been engaged in the work related to neural networks since I came into contact with them today 2、3 Years. , Among them, try to use tensorflow or pytorch Framework to implement some classic networks . However, the mechanism behind the back propagation is still vague .

gradient

Gradient is the fastest rising direction of a function , The fastest direction means that the shape of the direction function is very steep , That is also the direction in which the function drops fastest .

Although there are some theories 、 Gradient vanishing and node saturation can output a 1、2、3 But there is still no confidence to study deeply , After all, I haven't realized a back propagation and complete training process by myself . So the feeling is still floating on the surface , Know why but .

Because I have a period of free time recently 、 So I will take advantage of this break to sort out this part of knowledge 、 Learn more about

type Symbol explain expression dimension Scalar $n^L$nL It means the first one L The number of neurons in this layer vector $B^L$BL It means the first one L Layer bias $n^L\times 1$nL×1 matrix $W^L$WL It means the first one L The weight of the layer $n^L\times n^L$nL×nL vector $Z^L$ZL It means the first one L Layer input to the activation function $Z^L=W^L{A}^{(L-1)}+B^L$ZL=WLA(L−1)+BL$n^L\times 1$nL×1 vector $A^L$AL It means the first one L Layer output value $A^L=\sigma (Z^L)$AL=σ(ZL)$n^L\times 1$nL×1

We all probably know the process of training neural networks , Is to update network parameters , The direction of the update is to reduce the value of the loss function . That is to transform the learning problem into an optimization problem . So how to update parameters ? We need to calculate the derivative of the training parameters relative to the loss function , Then we solve the gradient , Then the gradient descent method is used to update the parameters , This iterative process , An optimal solution can be found to minimize the loss function .

We know that back propagation is mainly used to settle the derivatives of loss function relative to weight and bias

May have heard or read , A lot of information about the transmission of errors through back propagation in the network . And then according to the neurons w and b Contribution to deviation . That is, the error is distributed to each neuron . But the error here (error) What does that mean ？ What is the exact definition of this error ？ The answer is that these errors are contributed by each layer of neural network , And the error of a certain layer is shared on the basis of the error of subsequent layers , In the Internet $l$l Layer error ${\delta }^l$δl To express .

Back propagation is based on 4 Of a basic equation , The error is calculated from these equations ${\delta }^L$δL And the loss function , Here will be this 4 The equations are listed one by one

$$\begin{array}{cccc}& {\delta }^{(L)}={\mathrm{\nabla }}_{a}C\odot {\sigma }^{\mathrm{\prime }}(z^L)& & \text{(BP1)}\end{array}$$δ(L)=∇a​C⊙σ′(zL)(BP1)$$\begin{array}{cccc}& {\delta }^l=((w^l{)}^T{\delta }^{l+1})\odot {\sigma }^{\mathrm{\prime }}(z^l)& & \text{(BP1)}\end{array}$$δl=((wl)Tδl+1)⊙σ′(zl)(BP1)$$\begin{array}{cccc}& \frac{\mathrm{\partial }C}{\mathrm{\partial }{b}_j^l}={\delta }_j^l& & \text{(BP3)}\end{array}$$∂bjl​∂C​=δjl​(BP3)$$\begin{array}{cccc}& \frac{\mathrm{\partial }C}{\mathrm{\partial }{w}_{jk}^l}=a_k^{l-1}{\delta }_j^l& & \text{(BP4)}\end{array}$$∂wjkl​∂C​=akl−1​δjl​(BP4)

About how to interpret this 4 An equation , Later, I would like to use a share to explain .

class NeuralNetwork(object):
def __init__(self):
pass
def forward(self,x):
# Return to the forward propagation Z That is to say w and b A linear combination , Enter the value before activating the function
# Returns the output value of the activation function A
# z_s , a_s
pass
def backward(self,y,z_s,a_s):
# Returns the derivative of the learning parameter in the forward propagation dw db
pass
def train(self,x,y,batch_size=10,epochs=100,lr=0.001):
pass

We are all neural network learning process , That's the training process . There are mainly two stages Forward propagation and Back propagation

• In the forward propagation function , It mainly calculates the propagation Z and A, About Z and A See the table above for details
• Calculating learnable variables in back propagation w and b The derivative of

 def __init__(self,layers = [2 , 10, 1], activations=['sigmoid', 'sigmoid']):
assert(len(layers) == len(activations)+1)
self.layers = layers
self.activations = activations
self.weights = []
self.biases = []
for i in range(len(layers)-1):
self.weights.append(np.random.randn(layers[i+1], layers[i]))
self.biases.append(np.random.randn(layers[i+1], 1))

• layers Parameter is used to specify the number of neurons in each layer
• activations Specify activation functions for each layer , That is to say $\sigma (wx+b)$σ(wx+b)

To simply read the code assert(len(layers) == len(activations)+1)

for i in range(len(layers)-1):
self.weights.append(np.random.randn(layers[i+1], layers[i]))
self.biases.append(np.random.randn(layers[i+1], 1))

Because the weights connect the neurons of each layer w and b , The equation between two layers , The above code is right

Forward propagation

In forward propagation , Enter X Input to a_s in ,$z=wx+b$z=wx+b Then calculate the output $a=\sigma (z)$a=σ(z),

def feedforward(self, x):
# Returns the forward propagating value
a = np.copy(x)
z_s = []
a_s = [a]
for i in range(len(self.weights)):
activation_function = self.getActivationFunction(self.activations[i])
z_s.append(self.weights[i].dot(a) + self.biases[i])
a = activation_function(z_s[-1])
a_s.append(a)
return (z_s, a_s)

Here is the activation function , The return value of this function is a function , stay python use lambda To return a function , Here is a foreshadowing , It will be modified later .

 @staticmethod
def getActivationFunction(name):
if(name == 'sigmoid'):
return lambda x : np.exp(x)/(1+np.exp(x))
elif(name == 'linear'):
return lambda x : x
elif(name == 'relu'):
def relu(x):
y = np.copy(x)
y[y<0] = 0
return y
return relu
else:
print('Unknown activation function. linear is used')
return lambda x: x

[@staticmethod]
def getDerivitiveActivationFunction(name):
if(name == 'sigmoid'):
sig = lambda x : np.exp(x)/(1+np.exp(x))
return lambda x :sig(x)*(1-sig(x))
elif(name == 'linear'):
return lambda x: 1
elif(name == 'relu'):
def relu_diff(x):
y = np.copy(x)
y[y>=0] = 1
y[y<0] = 0
return y
return relu_diff
else:
print('Unknown activation function. linear is used')
return lambda x: 1

Back propagation

This is the focus of this sharing

 def backpropagation(self,y, z_s, a_s):
dw = [] # dC/dW
db = [] # dC/dB
deltas = [None] * len(self.weights) # delta = dC/dZ Calculate the error of each layer
# The last layer of error
deltas[-1] = ((y-a_s[-1])*(self.getDerivitiveActivationFunction(self.activations[-1]))(z_s[-1]))
# Back propagation
for i in reversed(range(len(deltas)-1)):
deltas[i] = self.weights[i+1].T.dot(deltas[i+1])*(self.getDerivitiveActivationFunction(self.activations[i])(z_s[i]))
#a= [print(d.shape) for d in deltas]
batch_size = y.shape[1]
db = [d.dot(np.ones((batch_size,1)))/float(batch_size) for d in deltas]
dw = [d.dot(a_s[i].T)/float(batch_size) for i,d in enumerate(deltas)]
# Return to weight (weight) matrix and Offset vector (biases)
return dw, db

First, calculate the error of the last layer according to BP1 The equation gives us the following formula

deltas[-1] = ((y-a_s[-1])*(self.getDerivitiveActivationFunction(self.activations[-1]))(z_s[-1]))

$${\delta }^L=(a^L-y)\sigma (z^L)$$δL=(aL−y)σ(zL)

Next, based on the ${\delta }^{l+1}$δl+1 Error to calculate the current layer ${\delta }^l$δl

$$\begin{array}{cccc}& {\delta }^l=((w^l{)}^T{\delta }^{l+1})\odot {\sigma }^{\mathrm{\prime }}(z^l)& & \text{(BP1)}\end{array}$$δl=((wl)Tδl+1)⊙σ′(zl)(BP1)

batch_size = y.shape[1]
db = [d.dot(np.ones((batch_size,1)))/float(batch_size) for d in deltas]
dw = [d.dot(a_s[i].T)/float(batch_size) for i,d in enumerate(deltas)]

$$\begin{array}{cccc}& \frac{\mathrm{\partial }C}{\mathrm{\partial }{b}_j^l}={\delta }_j^l& & \text{(BP3)}\end{array}$$∂bjl​∂C​=δjl​(BP3)$$\begin{array}{cccc}& \frac{\mathrm{\partial }C}{\mathrm{\partial }{w}_{jk}^l}=a_k^{l-1}{\delta }_j^l& & \text{(BP4)}\end{array}$$∂wjkl​∂C​=akl−1​δjl​(BP4)

Start training

 def train(self, x, y, batch_size=10, epochs=100, lr = 0.01):
# update weights and biases based on the output
for e in range(epochs):
i=0
while(i<len(y)):
x_batch = x[i:i+batch_size]
y_batch = y[i:i+batch_size]
i = i+batch_size
z_s, a_s = self.feedforward(x_batch)
dw, db = self.backpropagation(y_batch, z_s, a_s)
self.weights = [w+lr*dweight for w,dweight in zip(self.weights, dw)]
self.biases = [w+lr*dbias for w,dbias in zip(self.biases, db)]
# print("loss = {}".format(np.linalg.norm(a_s[-1]-y_batch) ))
