如何使用PHP Embed SAPI實現Opcodes查看器

編輯:PHP綜合

PHP提供了一個Embed SAPI,也就是說,PHP容許你在C/C++語言中調用PHP/ZE提供的函數。本文就通過基於Embed SAPI實現一個PHP的opcodes查看器。

首先,下載PHP源碼以供編譯, 我現在使用的是PHP5.3 alpha2

進入源碼目錄:

 ./configure --enable-embed --with-config-file-scan-dir=/etc/php.d --with-mysql  --with-config-file-path=/etc/
 ./make
 ./make install

最後,記得要將生成的libphp5.so復制到運行時庫的目錄,我直接拷貝到了/lib/, 否則會在運行你自己的embed程序的時候報錯:

./embed: error while loading shared libraries: libphp5.so: cannot open shared object file: No such file or directory

如果你對PHP的SAPI還不熟悉的話,我建議你看看我的這篇文章:深入理解Zend SAPIs(Zend SAPI Internals)
這個時候,你就可以在你的C代碼中,嵌入PHP腳本解析器了, 我的例子:

#include "sapi/embed/php_embed.h"
int main(int argc, char * argv[]){
 PHP_EMBED_START_BLOCK(argc,argv);
 char * script = " print 'Hello World!';";
 zend_eval_string(script, NULL,
          "Simple Hello World App" TSRMLS_CC);
 PHP_EMBED_END_BLOCK();
 return 0;
}

然後就是要指明include path了,一個簡單的Makefile

CC = gcc
CFLAGS = -I/usr/local/include/php/ \
   -I/usr/local/include/php/main \
   -I/usr/local/include/php/Zend \
   -I/usr/local/include/php/TSRM \
   -Wall -g
LDFLAGS = -lstdc++ -L/usr/local/lib -lphp5
ALL:
 $(CC) -o embed embed.cpp $(CFLAGS) $(LDFLAGS)

編譯成功以後, 運行,我們可以看到, stdout輸出 Hello World!

基於這個,我們就可以很容易的實現一個類似於vld的Opcodes dumper:
首先我們定義opcode的轉換函數(全部的opcodes可以查看Zend/zend_vm_opcodes.h);

char *opname(zend_uchar opcode){
 switch(opcode) {
  case ZEND_NOP: return "ZEND_NOP"; break;
  case ZEND_ADD: return "ZEND_ADD"; break;
  case ZEND_SUB: return "ZEND_SUB"; break;
  case ZEND_MUL: return "ZEND_MUL"; break;
  case ZEND_DIV: return "ZEND_DIV"; break;
  case ZEND_MOD: return "ZEND_MOD"; break;
  case ZEND_SL: return "ZEND_SL"; break;
  case ZEND_SR: return "ZEND_SR"; break;
  case ZEND_CONCAT: return "ZEND_CONCAT"; break;
  case ZEND_BW_OR: return "ZEND_BW_OR"; break;
  case ZEND_BW_AND: return "ZEND_BW_AND"; break;
  case ZEND_BW_XOR: return "ZEND_BW_XOR"; break;
  case ZEND_BW_NOT: return "ZEND_BW_NOT"; break;
  /*...省略 ....*/
  default : return "UNKNOW"; break;

然後定義zval和znode的輸出函數:

 char *format_zval(zval *z)
{
 static char buffer[BUFFER_LEN];
 int len;
 switch(z->type) {
  case IS_NULL:
   return "NULL";
  case IS_LONG:
  case IS_BOOL:
   snprintf(buffer, BUFFER_LEN, "%d", z->value.lval);
   return buffer;
  case IS_DOUBLE:
   snprintf(buffer, BUFFER_LEN, "%f", z->value.dval);
   return buffer;
  case IS_STRING:
   snprintf(buffer, BUFFER_LEN, "\"%s\"", z->value.str.val);
   return buffer;
  case IS_ARRAY:
  case IS_OBJECT:
  case IS_RESOURCE:
  case IS_CONSTANT:
  case IS_CONSTANT_ARRAY:
   return "";
  default:
   return "unknown";
 }
}
char * format_znode(znode *n){
 static char buffer[BUFFER_LEN];
 switch (n->op_type) {
  case IS_CONST:
   return format_zval(&n->u.constant);
   break;
  case IS_VAR:
   snprintf(buffer, BUFFER_LEN, "$%d", n->u.var/sizeof(temp_variable));
   return buffer;
   break;
  case IS_TMP_VAR:
   snprintf(buffer, BUFFER_LEN, "~%d", n->u.var/sizeof(temp_variable));
   return buffer;
   break;
  default:
   return "";
   break;
 }
}

 然後定義op_array的輸出函數:

void dump_op(zend_op *op, int num){
 printf("%5d %5d %30s %040s %040s %040s\n", num, op->lineno,
   opname(op->opcode),
   format_znode(&op->op1),
   format_znode(&op->op2),
   format_znode(&op->result)) ;
}
void dump_op_array(zend_op_array *op_array){
 if(op_array) {
  int i;
  printf("%5s %5s %30s %040s %040s %040s\n", "opnum", "line", "opcode", "op1", "op2", "result");
  for(i = 0; i < op_array->last; i++) {
   dump_op(&op_array->opcodes[i], i);
  }
 }
}

最後,就是程序的主函數了:

int main(int argc, char **argv){
 zend_op_array *op_array;
 zend_file_handle file_handle;
 if(argc != 2) {
  printf("usage: op_dumper <script>\n");
  return 1;
 }
 PHP_EMBED_START_BLOCK(argc,argv);
 printf("Script: %s\n", argv[1]);
 file_handle.filename = argv[1];
 file_handle.free_filename = 0;
 file_handle.type = ZEND_HANDLE_FILENAME;
 file_handle.opened_path = NULL;
 op_array = zend_compile_file(&file_handle, ZEND_INCLUDE TSRMLS_CC);
 if(!op_array) {
  printf("Error parsing script: %s\n", file_handle.filename);
  return 1;
 }
 dump_op_array(op_array);
 PHP_EMBED_END_BLOCK();
 return 0;
}

編譯,運行測試腳本(sample.php):

復制代碼 代碼如下:
sample.php:
   echo "laruence";

命令:

復制代碼 代碼如下:
./opcodes_dumper  sample.php

得到輸出結果(如果你對下面的結果很迷惑,那麼建議你再看看我的這篇文章:深入理解PHP原理之Opcodes):

Script: sample.php

opnum   line                         opcode                                      op1                                      op2                                   result
    0      2                      ZEND_ECHO                               "laruence"
    1      4                    ZEND_RETURN                                        1

呵呵,怎麼樣,是不是很好玩呢?
